TW-333 LED Universal Electronic Coin Mech

Arcade Express presents the TW-333 Universal Electronic Arcade Coin Mech. If you are looking for an Electronic Arcade Coin Mech with a more quality, this is the item you were looking for. Finish building your Arcade Cabinet with this beautiful coin mechanism in Matte Silver colour with a LED screen.

The TW-333 is a Universal Arcade Coin Mech, which means that it can be configured to accept any type of token / coin thanks to a simple mechanism: Just insert a sample of the token you want the Coin Mech to detect and thats it! This Coin Mech Acceptor also allows you to configure parameters such as the diameter, width and material of the coin to be used.

The TW-333 Coin mech has a small LED display on the front that indicates through a series of values its operation mode and function status. The meaning of each value is described in the instruction manual that you will find inside the box of the coin mech.

Two of the most interesting features of the TW-333 coin mech is its anti-theft system, which warns through its LED panel the activation of its anti-return security system. All these features makes the TW-333 Universal Arcade coin mech a very interesting and ideal product to be installed in bars, pubs and entertainment venues.

The TW-333 Coin mech includes all the necessary accessories (nuts, screws and wiring) for an easy and simple installation on your Arcade Cabinets coin door and a little instruction manual booklet for use and correct assembly.

Here you can watch a video showing you how to connect the Coin Mech to an arcade encoder:

Installation instructions:

1. Remove the plastic token sample that comes from factory inside the coin mech.
2. Slide the mechanism back to where the coin sample is located and insert the sample coin you are going to use.
3. Adjust the coin diameter slot with a screwdriver to prevent the coin mech from being activated by larger diameter coins.
4. Select the activation mechanism between Normally Open (NO) or Normally Closed (NC).
5. To change the sensitivity of coin acceptance, turn the VRtunning device right or left.

Features

• All accessories included for installation
• LED Screen
• DC12V voltage
• Coin diameter 22mm-28mm
• Coin width 1.7-2.2mm
• Temperature -15º +50º
• Front case material: PVC
